| 中央处理器 |
Intel® 13th/ 12th-Gen Core™ i7 /i5 /i3 (15W) , BGA CPU Onboard |
| 英特尔第12代CPU支持列表 |
i5-1235U
Intel® CoreTM i5-1235U processor with 2 P-cores and 8 E-cores up to 4.4GHz | 12MB Intel® Smart Cache |
Intel® Iris® Xe Graphics architecture with 80 EUs | Intel® code name Alder Lake-P (U-Series,15W)
i3-1215U
Intel® CoreTM i3-1215U processor with 2 P-cores and 4 E-cores up to 4.4GHz | 10MB Intel® Smart Cache |
Intel® UHD Graphics 64EU | Intel® code name Alder Lake-P (U-Series,15W)
|
| 英特尔第13代CPU支持列表 |
i5-1335U
Intel® CoreTM i5-1335U processor with 2 P-cores and 8 E-cores up to 4.6GHz | 12MB Intel® Smart Cache |
Intel® Iris® Xe Graphics architecture with 80 EUs | Intel® code name Raptor Lake-P (U-Series,15W)
i3-1315U
Intel® CoreTM i3-1315U processor with 2 P-cores and 4 E-cores up to 4.5GHz | 10MB Intel® Smart Cache |
Intel® UHD Graphics 64EU | Intel® code name Raptor Lake-P (U-Series,15W)
|
| GPU |
支持 TYPE A : 82 x 70 mm MXM GPU Module |
| MXM GPU支持列表 |
RTX4050-6G-35W
MXM GPU Module for Edge AI
computing , 82mm x 70mm , NVIDIA RTX4050/6GB GDDR6 with 35W low-power consumption to provide single-precision
8.218 TFLOPS and integer 194 TOPS computing capability.
A2000-8G
NVIDIA A2000/8GB GDDR6 MXM GPU Module for Edge AI computing , 82mm x 70mm
with 38/50W low-power consumption to provide single-precision 8.958 TFLOPS .
MX550/4GB
NVIDIA MX550/4GB GDDR6 MXM GPU module which is the best inference choice for embedded edge AI application , 82mm x 70mm with 35W low-power consumption to provide single-precision 4.5 TFLOPS and 1024 CUDA computing capability.
|
| 内存 |
配备2个 SO-DIMM DDR5插槽，最大扩展64G |
| 显示 |
2x Display （ 1x Display Port, 4096*2304@60Hz 1x HDMI , 4096*2160@60Hz） |
| LAN |
2xLAN(1x 2.5 GbE , 1x GbE RJ45或M12可选） |
| 串口 |
2x串口（1x RS232/422/485, 1x RS232) |
| USB |
8x USB ( 6x USB 3.2, 2x USB 2.0) |
| 音频 |
1个3.5mm插孔，用于麦克风输入和输出 |
| 存储 |
2x M.2 2242 M key (SATA III SSD) , Support Raid 0/1 , (1x M.2 2242 share with M.2 3052) |
| 内部扩展 |
1x M.2 2242/3052 M-B key with SIM slot, support 4G/5G
1x Full Size Mini-PCIe with SIM slot, support 4G/5G
1x M.2 Key E Type 2230 for WIFI/BT/GPS
|
| 尺寸 |
145(W) x 125(D) x 90.1 (H) mm |
| 重量 |
1.1 Kg |
| 电源 |
1x 3-pin 6~48V DC输入的可插拔接线端子
200V/1ms 浪涌保护、反向电压、过电压、欠电压、过电流保护
1x 电源按钮
1x 4-pin 点火/远程电源控制的可插拔接线端子
|
| 工作环境 |
工作温度 : -40°C ~ 70 °C (According to CPU) , GPU TGP 35W ( 50 °C )
存储温度 : -40°C to 85°C
工作湿度 : 0~95%(non-condensing ）
存储湿度: 10~90%
|
| 操作系统 |
windows10、11
Ubuntu20.04、22.04
|
| Vibration / Shock |
Vibration test according to MIL-STD-810H, Method 514.8, Category 4
Shock test according to MIL-STD-810H, Method 516.8, Procedure I
|
| EMC |
CE/FCC Class A , according to EN 55032 & EN 55035 , (E-Mark / EN50155 / EN45545-2 by request) |
| 结构 |
铝制金属机箱，双边散热。 |
