| CPU支持 |
Onboard Intel® Celeron® processor J1900 Quad Core 2.0GHz
Support Intel® Atom™ E3800 processor family from Single Core E3815, Dual Core E3825/E3826/E3827 and Quad Core E3845 with difference SKUs |
| 内存 |
2 x DDR3L SO-DIMM socket, support DDR3L 1066/1333 8GB RAM max., un-buffered and non-ECC |
| 显示选项 |
Dual independent display
DVI-I and DP |
| I/O接口-前面板 |
ATX power on/off switch
LEDs for HDD LED, Batty LEDs, Power LED, COM port Tx/Rx, 5x programmable GPO LEDs
1 x External SD Card
1 x SIM card holder
2 x Intel® I210AT GbE LAN ports, support WoL, Teaming and PXE
1 x DP display output
1 x DVI-I display output
1 x USB 3.0 (900mA per each)
3 x USB 2.0 (500mA per each)
2 x RS232/422/485 support auto flow control
Jumper-free setting on RS232/422/485
Support 2.5KV isolation protection on COM1
1 x 3-pin DC input, Typical 24V DC input with +/-20% range |
| 存储设备 |
1 x 2.5" SSD/HDD(SATA 2.0) --front accessible
1 x SD card (Data storage only)
1 x mSATA |
| 扩展槽 |
NIFE 200P2: two PCI expansion
- Add-on card length: 176mm max.
- Power consumption: 10W/slot max.
NIFE 200P2E: one PCI and one PCIe x4 expansion
- Add-on card length: 176mm max.
- Power consumption: 10W/slot max.
NIFE 200E2: two PCIe x1 expansion
- Add-on card length: 176mm max.
- Power consumption: 10W/slot max.
2 x mini-PCIe socket for optional Wi-Fi/3.5G/4G LTE/fieldbus modules |
| 电源需求 |
Typical 24V DC input with +/-20% range, with reverse polarity protection
1 x optional 24V, 60W power adapter |
| 体积 |
151mm (W) x 157mm (D) x 230mm (H) |
| 结构 |
Aluminum and metal chassis with fanless design |
| 环境 |
Operating temperature:
- Ambient with air flow: -5°C to 55°C
- (according to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
Storage temperature: -20°C to 80°C
Relative humidity: 10% to 95% (non-condensing)
Shock protection:
- HDD: 20G, half sine, 11ms, IEC60068-2-27
- SSD: 50G, half sine, 11ms, IEC60068-2-27
Vibration protection w/ SSD condition:
- Random: 2Grms @ 5~500Hz, IEC60068-2-64
- Sinusoidal: 2Grms @ 5~500Hz, IEC60068-2-64 |
| 认证 |
CE Approval
- EN61000-6-2
- EN61000-6-4
FCC Class A
LVD
UL60950 |
| 支持操作系统 |
Windows 8, 32bit/64bit
Windows Embedded Standard 8, 32bt/64bit
Windows 7, 32bit/64bit
Windows Embedded Standard 7, 32bit/64bit
Linux Kernel version 3.8.0 |
