| 核心系统 |
CPU：Intel® Core™ i7-4700EQ 2.4 GHz
DMI：5 GT/s
芯片组：Intel® QM87 Express 芯片组
内存：最高支持 16 GB SO-DIMM 内存，支持双通道 DDR3L SDRAM, 1333/1600 MHz 内存 |
| 芯片组 |
Intel® QM87 Express chipset |
| 内存 |
Up to 16 GB SO-DIMM memory
Supports dual-channel DDR3L SDRAM, 1333/1600 MHz |
| 显示 |
DisplayPort：3840 x 2160 @ 60 Hz
DVI：1920 x 1200 @ 60 Hz
DisplayPort adapters to other standards are available, maximum resolution achieved is dependent on the adapter chosen
|
| 存储 |
Hard Drive：500 GB (or greater) SATA hard drive2
Solid State Drive：240GB (or greater) SATA SSD
|
| 网络接口 |
One Intel® I210 Gigabit Ethernet Controller and one Intel® I217 Gigabit Ethernet
Two RJ-45 connectors with speed/link/active LED on the faceplate |
| 面板接口 |
USB：2 x USB 3.0 and 4 x USB 2.0 on the faceplate
GPIB：Onboard IEEE488 GPIB controller Micro-D 25-pin connector on the faceplate (ACL-IEEE488-MD1-A cable required)
Trigger I/O：SMB connector on the faceplate to route an external trigger signal to/from PXI trigger bus
|
| 机械结构&电气特性 |
--------------------------------------------------------------------------------------------------------------------
|
| Dimensions |
3U/4-slot PXI/CompactPCI standard |
| Slot Requirements |
1 system slot plus 3 controller expansion slots |
| Weight |
1 kg (2.2 lbs) |
| Operating Temp. |
0 to 50°C (32˚F to 122˚F) (w/ HDD)
0 to 55°C (32˚F to 131˚F) (w/ SSD) |
| Storage Temp. |
-20 to 70°C (-4˚F to 158˚F) |
| Relative Humidity |
5 to 95%, non-condensing |
| Shock |
30 G, half-sine, 11 ms pulse duration |
| Vibration |
Operating: 5 to 500 Hz, 0.5 GRMS, 3 axes
Non-operating: 5 to 500 Hz, 2.46 GRMS, 3 axes |
| Emissions Compliance |
EN 61326-1, FCC Class A |
| CE Compliance |
Immunity: EN 61326-1 |
