| CPU |
Onboard Intel® Atom™ processor E3826 Dual Core 1.46GHz
Support Intel® Atom™ E3800 processor family from single core E3815,
Dual Core E3825/E3826/E3827 and Quad Core E3845 with difference SKUs
|
| 前面板I/O 接口 |
ATX power on/off switch
LEDs for power status, HDD access, battery Low, 2 x programing LEDs, 4x Tx/Rx LEDs
1 x External CFast socket
1 x SIM card holder
1 x EtherCAT port, 1 x Intel® I210IT GbE LAN port
1 x DVI-I display output
1 x USB 3.0 (900mA per each)
1 x USB 2.0 (500mA per each)
2 x RS232/422/485 with 2.5KV isolation protection, support auto flow control
- Jumper-free setting on RS232/422/485
- Support RI function on COM2
1 x 2-pin remote power On/Off switch
1 x 3-pic DC input, Typical 24V DC input with +/-20% range
|
| 储存 |
1 x CFast (SATA 2.0)
1 x 2.5" SSD (SATA 2.0)
|
| 扩展槽 |
1 x Mini-PCIe socket for optional Wi-Fi/3.5G/4G LTE |
| 电源 |
Typical 24V DC input with +/-20% range
1 x optional 24V, 60W power adapter
|
| 尺寸 |
58mm (W) x 135.5mm (D) x 192.5mm (H) |
| 结构 |
Aluminum and metal chassis with fanless design |
| 工作环境 |
Operating temperature:
Ambient with air flow: -20°C to 70°C with industrial grade device (According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
Storage temperature: -30°C to 85°C
Relative humidity: 10% to 95% (non-condensing)
Shock protection:
- SSD: 20G, half sine, 11ms, IEC60068-2-27
- CFast: 50G, half sine, 11ms, IEC60068-2-27
Vibration protection w/ CFast & SSD condition:
- Random: 2Grms @ 5 ~ 500Hz, IEC60068-2-64
- Sinusoidal: 2Grms @ 5 ~ 500Hz, IEC60068-2-6
|
| 认证 |
CEFCC Class A |
